Customised Automatic Die Cutting Machine Auto Lubrication Industrial Die Cutter

Brand Name : FINTEECH

Model Number : FB-HT1060AR

Certification : CE

Place of Origin : China

MOQ : 1set

Packaging Details : wooden case

Delivery Time : 20-30 days

Payment Terms : TT/LC

Supply Ability : 10 sets per day

After-sales service provided : Engineers available to service machinery overseas,Video technical support,Field installation,commissioning and training,Online support

Condition : New

Type : Die-cutting Machine,Paper Cutting Machine,Label cutter,Other,Packing Machine

Computerized : Yes,Semi-Automatic,No

Product name : Automatic Roll Film/ Mylar/Aluminum Foil Die Cutting Machine,automatic paper die cutting punching machine price,BASCOCUT multi sheet cutter,Automatic rotary die cutting machine for corrugated carton box,small size die cutting machine

Function : die cutting,stamping,Automatic Die-cutting Machine in electric field,Manual Creasing,High Effieciency

Name : Die Cutting Machine

Usage : sticker,trademark,Food Forming Machine,label,heat transfer industry

Automatic grade : Automatic,Semi-Automatic

Color : Requirement,Optional Color

Contact Now

Automatic Die Cutting Machine Cutting Solution
Experience unmatched efficiency with our premium automatic die cutting solution designed to meet diverse business needs across multiple industries.
Product Attributes
Attribute Value
After-sales service Engineers available overseas, Video technical support, Field installation, Online support
Condition New
Type Die-cutting Machine, Paper Cutting Machine, Label cutter, Packing Machine
Computerized Yes, Semi-Automatic, No
Function Die cutting, stamping, creasing, high efficiency operation
Usage Stickers, trademarks, labels, food forming, heat transfer industry
Automatic grade Automatic, Semi-Automatic
Color Customizable to requirements
Advanced Machine Features
  • Precision Feeder: Handles materials from 90g/m² thin paper to 1000g/m² cardboard
  • Ultrasonic Double Sheet Detector: Non-contact detection prevents material scratches
  • Quick Mold Locking: Center-line system reduces setup time
  • Adjustable Plate System: 5mm hardened cutting plate with ±0.9mm micro adjustment
  • Advanced Gripper Bar: Smooth operation with unique eccentric worm gear drive
  • Automatic Collection: Non-stop collecting devices for continuous operation
  • Premium Components: Germany Becker oil-free blower and vacuum pump
  • Auto Lubrication: Centralized system ensures optimal performance
Technical Specifications
Model FB-HT1060AR
Sheet Size Range 400×350mm to 1060×760mm
Cutting Size Up to 1060×745mm
Material Range Paper: 80-2000g/m² (0.1-2mm), Corrugated board: up to 4mm
Cutting Precision ≤±0.075mm
Maximum Speed 8000 sheets/hour
Cutting Pressure 600T maximum
Heating System 20 zones, adjustable 40-180℃
Power Requirements Main motor: 15KW, Total: 35KW
Machine Dimensions 6703×4518×2502mm (L×W×H)
Weight 21T
Key Advantages
  • Industry-leading ≤±0.075mm cutting precision
  • Versatile material handling capabilities
  • Advanced 20-zone heating system
  • High-speed production up to 8000 sheets/hour
  • Robust 600T cutting pressure capacity
  • Customised Automatic Die Cutting Machine Auto Lubrication Industrial Die Cutter Customised Automatic Die Cutting Machine Auto Lubrication Industrial Die Cutter
